46x26 digital rack mixer with 24 recallable XMAX preamps

DESCRIPTION


The StudioLive® 24R digital mixer is four audio tools in two compact rackspaces. Use it as a standalone digital mixer with UC Surface remote mixing software. Pair it with your StudioLive Series III console mixer to use as a stage box or integrated monitor mixer. Connect it with EarMix 16M monitor mixers for the ultimate personal monitor system. Plug it into your studio computer, and you have a continuously bidirectional, 128-channel (64x64) USB audio interface with modeled vintage dynamics and EQ plug-ins on every input and bus. Whether used standalone or as part of a complete audio system, no other rackmount digital mixer is as flexible or as powerful.

Inside the StudioLive 24R, the single-core PreSonus® FLEX DSP Engine powers 40 mixing channels, 22 mix buses, and 270 simultaneous processors, including 4 stereo effects and Fat Channel plug-in models on every input channel and mix bus. This is a true 24-channel digital mixer that can comfortably fit in any size rig. Simply connect it to a standard wireless router and control every mix parameter from your iPad®, Android™ tablet, or Windows® Touch computer using UC Surface. UC Surface was designed to make mixing on a touch screen as intuitive as mixing on faders.

An integrated 128-channel (64x64) audio interface lets you record with digitally recallable analog preamps and a complete rack of vintage EQ and dynamics processors for every channel and bus. Modeled after classic analog studio designs, these compressor and EQ plug-ins load both natively on the StudioLive 24R and inside Studio One®, providing the ultimate mixing and recording flexibility.

See more

FEATURES


  • Powered by the new dual-core PreSonus® FLEX DSP Engine to provide the most processing of any digital mixer in its class
  • 36 input-channel digital rack mixer with 24 local digitally controlled XMAX mic/line inputs and FLEX FX returns
  • 26 mix buses: 16 FlexMixes (Aux, Subgroup, Matrix), 4 dedicated FLEX FX buses, and Stereo Main bus
  • 286 simultaneous processors: HPF, Gate/Expander Compressor with Fat Channel plug-in models, 4-band/6-band parametric EQ with Fat Channel plug-in models, Limiter
  • 31-band graphic EQ
  • 4 FLEX FX slots featuring legendary classic reverb emulations and delays
  • State Space Modeled Fat Channel compressor and EQ plug-ins available on every input channel and output bus
  • FLEX FX multi-effects processor with 4 slots to load legendary reverb emulations and delays with 4 dedicated effects buses
  • 24 DCAs to control groups of channels
  • 128-channel (64x64) recording over USB
  • Digital Audio Bit Depth
  • 24
  • Digital Audio Dynamic Range
  • ADC Dynamic Range: 115 dB (A-Weighted, 48 kHz), DAC Dynamic Range: 115 dB (A-Weighted, 48 kHz)
  • Digital Audio Reference Level For Zero dBFS
  • =+18 dBu
  • Digital Audio Total System Latency
  • 1.9 ms (local routing, analog in-analog out, all processing active)
  • Line Input Connection Type
  • RCA Female, Unbalanced (Stereo Pair)
  • Line Inputs Maximum Level
  • +12 dBu, ±0.5 dBu
  • Microphone Input Connection Type
  • Combo Locking XLR Mic - 1/4” TRS Line
  • Microphone Preamp Common Mode Rejection Ratio
  • 65 dB (1 kHz at Unity Gain)
  • Microphone Preamp Frequency Response
  • 20-20 kHz (±0.5 dBu at Unity Gain)
  • Microphone Preamp Gain Control Range
  • 0 dB to 60 dB (±1 dB)
  • Microphone Preamp Input Impedance
  • 1 kΩ
  • Microphone Preamp Maximum Input Level
  • =+12 dBu (Unity Gain)
  • Microphone Preamp Signal To Noise Ratio
  • 94 dB (Ref = +4 dB, 20 kHz BW, Unity Gain, A-Weighted)
  • Microphone Preamp Total Harmonic Distortion
  • <0.005%, +4 dBu, 20-20 kHz, Unity Gain, Unweighted
  • Headphone Outputs Frequency Response
  • 20 Hz to 20 kHz, +/-0.5 dB
  • Headphone Outputs Maximum Output
  • 100 mW/ch. @ 60Ω Load
  • Headphone Outputs Signal To Noise Ratio
  • 96 dB, 1 kHz, Maximum Gain, 20 Hz BW, Unweighted
  • Headphone Outputs Total Harmonic Distortion
  • 0.01%, 1 kHz, Maximum Gain, 20 Hz BW, Unweighted
  • Line Outputs Connection Type
  • 1/4" TRS, Balanced
  • Line Outputs Maximum Output Level
  • =+18 dBu, ±0.5 dBu
  • Line Outputs Output Impedance
  • 100 Ohms
